CAL series vacuum auto-loader device with stainless steel material hopper, high performance vacuum motor, motor protective device and material shortage alarm. Compact size, light weight, strong vacuum suction, easy installation, simple operation, and durability.
Features include:
- Compact, easy installation, strong vacuum power
- Stainless steel material hopper for lightness, durability and cleanness
- Microprocessor controlling unit
- Automatic warning buzzer for lack of materials
- Automatic protective devise for motor overload
- CAL-600F features manual or automatic reverse cleaning
Power Supply:
Technical Data 1 Phase 220V 60Hz
| Model | Motor | Conveying Capacity | Static Wind Pressure (max) | Filter (mm) | Material Hopper Volume | Conveying Tube I.D. | External Dimensions (HxWxDmm) | Weight | |
| Type | Spec | ||||||||
|
CAL-300LD |
Carbon brush | 950w 1Ø | 400kg/hr | 1500mmAq | 186Øx60H | 8Lit | Ø38mm | 690x420x440 | 15kg |
|
CAL-300F |
Induction | 950w 1Ø | 400kg/hr | 1500mmAq | 186Øx60H | 8Lit | Ø38mm | 615x420x440 | 13kg |
|
CAL-600F |
Induction | 1HP 3Ø | 450kg/hr | 2000mmAq | 186Øx60H | 8Lit | Ø38mm | 740x445x440 | 27kg |
